High Efficient Digital Display ACP Vertical Panel Saw

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
The High Efficient Digital Display ACP Vertical Panel Saw is developed by adopting German classic structure technology and idea of profile processing in combination with the professional design of our company. The machine is mainly used for the grooving and cutting of Panels of ACP,Aluminium Sheet,MDF,Wood,etc.
1. Adopting imported hard alloy saw blades ensures high stability in high-speed running, efficiency and long life.
2. Grooving depth is controlled by special eccentric bearing structure, and adjustment can be done at random between 0 to 8mm; the adjustment is easy and the precision is high. The grooving depth deviation ≤0.15mm.
3. The cutting head can realize the horizontal and vertical cutting or grooving. It’s of easy adjusting, accurate positioning, flexible operating and stability.
Availability:
Quantity:

Features

  • ACP vertical panel saw

  • High efficiency grooves and cuts possible for all variant machining

  • Ideal machine for high-volume series panel production of horizontal and vertical grooving and cutting

  • Equipped with 2 grooving blades and 1 cutting blade as standard

  • Equipped with safety hoods and safety sensor as standard

  • Equipped with convenient lift lever and moveable step roller as standard

  • 2.2KW motors for fast and convenient grooving and cutting

  • 50mm max. cutting depth and 8mm max grooving depth

  • 250mm diameter grooving and cutting blades for free panel working

Cutting length variants

  • 3,000 mm

  • 4,500 mm

  • 6,000 mm

  • 7,500 mm

  • Additional lengths on request

Options

  • Saw blades

  • Digital Ruler

  • Dust Collector

  • Upload or unload panel table


Model No.

OT-VP416

Grooving/Cutting Length

4100mm

Grooving/Cutting Height

1600mm

Deviation of Rectangular Diagonal   formed by two horizontal Grooving and two vertical Grooving

>2000mm-≤2.5mm

Grooving Depth

0-8mm

Grooving Blade I Dia.

Φ250mm

Grooving Blade II Dia.

Φ250mm

Cutting Blade Dia.

Φ250mm

Motor Power

2.2KW

Motor Speed

5400rpm

Voltage

3Phase,380V/415/220,50Hz   or Custom-made

Working Air   Pressure

0.6Mpa-0.8Mpa

Dimension (L ×   W × H)

5400x1300x2600mm

Weight of   machine

1500Kg
