Large Multi Angle Aluminium Facade Notching Saw

loading

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
This Large Multi Angle Aluminium Facade Notching Saw is applicable for Different Angle Notching and Compound Angle Cutting of Curtain Wall Aluminium Metal Profiles with Simple Operation, it adopts Creative German Design Concepts and Production Technics in accordance with European High Standards and Continuous Optimization.

It adopts High Precision Spindle Motor,Vertical 700mm Blade and Horizontal 650mm Blade, the worktable is adjustable in different angle with Digital Ruler Display,it's easy to operate and maintain.

It adopts Creative German Design and Casting Machine Base, as well as Famous High Precision Components, specially the Powerful Professional Assembly Engineering Technics that Well Trained by German Engineers,which ensures the wide processing range for large and complicated profiles and High Accuracy for High End Processing Requirements.
Availability:
Quantity:

Features

· Large notching saw

· Variable notching possibilities for mullion and transom combinations of facade,skylights,aluminium bridges,etc

· Saw blades moving by linear guide and fixed workpieces ensures precise and safe notching

· Both saw blades are adjustable in height and depth simultaneously by handle wheel with digital ruler display

· Tilting angle ±45° of both saw blades ensures variable notching

· High efficient cuts possible for all variant cutting

· Liquid mist diffuser coolant system for aluminium machining

· Equipped with saw blades and safety hoods as standard

· Equipped with digital display system for convenient readout

· Equipped high precision linear guide as standard

· Horizontal and vertical pneumatic material clamping units

· 3.0KW motors for fast and thick profile bar cutting

· 700mm and 650mm dia. Blades provide large notching range

· Hydro-pneumatic feeding as standard

Options

· Label printer

· Saw blades

· Safety fence

· Roller conveyor

· Mobile workpiece support

· Material clamping units

· Stationary and/or travelling roller conveyor

· High performance cutting fluid for aluminium machining

Model No.

OYT-M700

Cutting Width

300mm

Cutting Height

275mm

Cutting Depth

250mm

Cutting Angle

±45°

Worktable Adjusting   Angle

±45°

Vertical Blade   Dia.

Ф700mm

Horizontal   Blade Dia.

Ф650mm

Motor Power

3.0KWx2

Motor Speed

3000rpm

Machining   Accuracy

±0.1mm/m

Cooling Type

Liquid Diffuser

Lubrication   System

Central Auto

Voltage

3Phase,380V/415/220,50Hz   or Custom-made

Working Air Pressure

0.6Mpa-0.8Mpa

Dimension (L ×   W × H)

3500x1800x1800mm

Working Air   Pressure

0.6Mpa-0.8Mpa

Machine Weight

2500Kg
